VC ID : 100
VC Type : VLAN
Destination : 3.3.3.9
Transmit VC Label : 100
Receive VC Label : 100
Control Word : Disable
VCCV Capabilty : Disable
Tunnel Policy : --
PW Template Name : pwt
Traffic Behavior : --
Main or Secondary : Main
VC tunnel/token info : 1 tunnels/tokens
NO.0 TNL Type : lsp , TNL ID : 0x2002003
Create time : 0 days, 0 hours, 13 minutes, 7 seconds
UP time : 0 days, 0 hours, 10 minutes, 23 seconds
Last change time : 0 days, 0 hours, 10 minutes, 23 seconds
5.5 Configuring a Dynamic PW
This section describes how to configure the dynamic PW. A dynamic PW uses the extended
LDP protocol to transmit Layer 2 information and VC labels.
5.5.1 Establishing the Configuration Task
5.5.2 Enabling MPLS L2VPN
5.5.3 Creating a Dynamic PW
5.5.4 Checking the Configuration
5.5.1 Establishing the Configuration Task
Applicable Environment
A dynamic PW uses the extended LDP protocol to transmit Layer 2 information and VC labels.
The dynamic PW needs to be configured on the PEs (or U-PEs), which are connected to the CEs,
at both ends of a PW.
Pre-configuration Tasks
Before configuring a dynamic PW, complete the following tasks:
l Configuring IGP on the PEs and P of the MPLS backbone network to realize the IP
connectivity of the backbone network
l Configuring basic MPLS functions on the backbone network
l Establishing the tunnel of a corresponding type between PEs according to the tunnel policy
l Setting up a remote LDP session between PEs
Data Preparation
To configure a dynamic PW, you need the following data.
No.
Data
1 Type and number of the interface connected to the CE
