1. Enable MPLS on the PEs.
2. Enable the MPLS L2VPN.
3. Configure VLL instances and CE connections.
Data Preparation
To complete the configuration, you need the following data:
l Names of VPN instances and RDs
l Names and IDs of the CEs (The CE IDs are globally unique.) CE range, namely, the label
block
Procedure
Step 1 Configure the addresses of the VLANIF interfaces of CE1 and CE2 according to Figure 4-8 and
the IDs of the VLANs to which the interfaces belong.
The configuration details are not mentioned here.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Configure a local connection in Kompella mode.
# Configure basic MPLS functions.
[PE] interface loopback 1
[PE-LoopBack1] ip address 1.1.1.9 32
[PE-LoopBack1] quit
[PE] mpls lsr-id 1.1.1.9
[PE] mpls
[PE-mpls] quit
# Configure MPLS L2VPN and CE connections.
[PE] mpls l2vpn
[PE-l2vpn] quit
[PE] mpls l2vpn vpn1 encapsulation vlan
[PE-mpls-l2vpn-vpn1] route-distinguisher 100:1
[PE-mpls-l2vpn-vpn1] ce ce1 id 1 range 10
[PE-mpls-l2vpn-ce-vpn1-ce1] connection ce-offset 2 interface vlanif 10
[PE-mpls-l2vpn-ce-vpn1-ce1] quit
[PE-mpls-l2vpn-vpn1] ce ce2 id 2 range 10
[PE-mpls-l2vpn-ce-vpn1-ce2] connection ce-offset 1 interface vlanif 20
[PE-mpls-l2vpn-ce-vpn1-ce2] quit
[PE-mpls-l2vpn-vpn1] quit
Step 3 Verify the configuration.
After the configuration, run the display mpls l2vpn connection command on the PE. You can
see that two L2VPN connections are set up and they are in Up state.
<PE> display mpls l2vpn connection
2 total connections,
connections: 2 up, 0 down, 2 local, 0 remote, 0 unknown
VPN name: vpn1,
2 total connections,
connections: 2 up, 0 down, 2 local, 0 remote, 0 unknown
CE name: ce1, id: 1,
Rid type status peer-id route-distinguisher interface
