3. Establish an IBGP adjacency between the PE and the ASBR-PE in an AS.
4. Set up a Kompella VLL connection between the PE and the ASBR-PE in an AS.
Data Preparation
To complete the configuration, you need the following data:
l OSPF data
l MPLS LSR-IDs of PE and ASBR-PEs
l L2VPN instance name, RD, and VPN target on the PE and the ASBR-PE
l CE connection name, CE ID, CE range (10 by default), and default offset (1 or 0, the default
is 0) on the PE and ASBR-PEs
Procedure
Step 1 Configure the IDs of the VLANs to which the interfaces belong according to Figure 4-11.
The configuration procedure is not mentioned.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Configure an IGP protocol on the backbone network.
PEs and ASBR-PEs on the MPLS backbone network can communicate with each other by using
IGP. OSPF is used as the IGP protocol in this example.
The configuration procedure is not mentioned. Note that the address of Loopback1 must be
advertised to the IBGP peer.
After the configuration, the ASBR-PE and the PEs in the same AS can learn the Loopback1
addresses of each other. Run the display ip routing-table command, and you can see that the
ASBR and the PEs in the same AS can learn the Loopback1 addresses of each other.
Take the display on PE1 for example.
<PE1> display ip routing-table
Route Flags: R - relied, D - download to fib
------------------------------------------------------------------------------
Routing Tables: Public
Destinations : 7 Routes : 7
Destination/Mask Proto Pre Cost Flags NextHop Interface
1.1.1.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0
2.2.2.2/32 OSPF 10 2 D 20.1.1.2 Vlanif20
20.1.1.0/30 Direct 0 0 D 20.1.1.1 Vlanif20
20.1.1.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0
20.1.1.2/32 Direct 0 0 D 20.1.1.2 Vlanif20
127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0
127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0
The ASBR-PE and the PEs in the same AS can ping each other's Loopback1 address.
<PE1> ping 2.2.2.2
PING 2.2.2.2: 56 data bytes, press CTRL_C to break
Reply from 2.2.2.2: bytes=56 Sequence=1 ttl=255 time=90 ms
Reply from 2.2.2.2: bytes=56 Sequence=2 ttl=255 time=90 ms
Reply from 2.2.2.2: bytes=56 Sequence=3 ttl=255 time=60 ms
Reply from 2.2.2.2: bytes=56 Sequence=4 ttl=255 time=90 ms
Reply from 2.2.2.2: bytes=56 Sequence=5 ttl=255 time=60 ms
4 VLL Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN
4-78 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2009-08-20)
