GigabitEthernet2/0/2 VLANIF 30 100.34.1.1/30
Loopback1 - 4.4.4.4/32
CE1 GigabitEthernet1/0/0 VLANIF 10 10.1.1.1/30
GigabitEthernet1/0/0 VLANIF 10 10.1.2.1/30
GigabitEthernet1/0/1 VLANIF 70 10.1.3.1/24
CE2 GigabitEthernet1/0/0 VLANIF 60 10.1.1.2/30
GigabitEthernet1/0/1 VLANIF 50 10.1.2.2/30
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure OSPF on the backbone network.
2. Set up an MPLS TE tunnel between PE1 and PE3, and an LSP between PE1 and PE2.
3. Set up MPLS LDP sessions between PE1 and PE2, and between PE1 and PE3.
4. Set up an MPLS LDP session between PE1 and PE3.
5. Use PW templates to configure PWs on PEs. You need to use tunnel policies to configure
the master PW because the master PW uses the MPLS TE tunnel.
Data Preparation
To complete the configuration, you need the following data:
l Tunnel policies
l Bandwidth for MPLS TE tunnels
l Name of the remote peer of MPLS LDP
l VC IDs of the master PW and the backup PW
l Name of the PW template
Procedure
Step 1 Configure the IDs of the VLANs to which the interfaces belong according to Figure 4-12.
The configuration procedure is not mentioned.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Assign an IP address to the interface connecting CE to PE.
# Configure CE1.
<Quidway> system-view
[Quidway] sysname CE1
[CE1] interface vlanif 10
[CE1-Vlanif10] ip address 10.1.1.1 30
[CE1-Vlanif10] ip address 10.1.2.1 30 sub
[CE1-Vlanif10] quit
4 VLL Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - VPN
4-88 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2009-08-20)
