l Identical L2VC IDs of PEs on the two ends of a PW
l MPLS LSR ID of each PE and P
l Peer address of PE
Procedure
Step 1 Configure the IDs of the VLANs to which the interfaces of CE, PE, and P belong according to
Figure 5-11.
NOTE
The S9300 only allows the CE to access the PE through a trunk.
Step 2 Assign an IP address to the VLANIF interface connecting the CE to the PE.
The configuration procedure is not mentioned.
Step 3 Configure an IGP protocol on the MPLS backbone network.
The OSPF protocol is used in this example.
The configuration procedure is not mentioned.
After the configuration, run the display ip routing-table command. You can see that PE1 and
PE2 can learn the loopback 0 address of each other that is discovered by the OSPF protocol, and
can ping each other.
<PE1> display ip routing-table
Route Flags: R - relied, D - download to fib
------------------------------------------------------------------------------
Routing Tables: Public
Destinations : 9 Routes : 9
Destination/Mask Proto Pre Cost Flags NextHop Interface
10.1.1.0/24 Direct 0 0 D 10.1.1.1 Vlanif20
10.1.1.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0
10.1.1.2/32 Direct 0 0 D 10.1.1.2 Vlanif20
10.2.2.0/24 OSPF 10 2 D 10.1.1.2 Vlanif20
127.0.0.0/8 Direct 0 0 D 127.0.0.1 InLoopBack0
127.0.0.1/32 Direct 0 0 D 127.0.0.1 InLoopBack0
192.2.2.2/32 Direct 0 0 D 127.0.0.1 InLoopBack0
192.3.3.3/32 OSPF 10 3 D 10.1.1.2 Vlanif20
192.4.4.4/32 OSPF 10 2 D 10.1.1.2 Vlanif20
<PE1> ping 192.3.3.3
PING 192.3.3.3: 56 data bytes, press CTRL_C to break
Reply from 192.3.3.3: bytes=56 Sequence=1 ttl=254 time=230 ms
Reply from 192.3.3.3: bytes=56 Sequence=2 ttl=254 time=120 ms
Reply from 192.3.3.3: bytes=56 Sequence=3 ttl=254 time=120 ms
Reply from 192.3.3.3: bytes=56 Sequence=4 ttl=254 time=120 ms
Reply from 192.3.3.3: bytes=56 Sequence=5 ttl=254 time=90 ms
--- 192.3.3.3 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
0.00% packet loss
round-trip min/avg/max = 90/136/230 ms
Step 4 Enable MPLS and set up tunnels and LDP sessions.
Enable MPLS on the backbone network, set up LSPs and LDP remote sessions between the PEs.
The configuration procedure is not mentioned.
