Loopback1 - 1.1.1.9/32
P GigabitEthernet 1/0/0 VLANIF 30 100.1.1.2/24
GigabitEthernet 2/0/0 VLANIF 40 100.1.2.1/24
Loopback1 - 2.2.2.9/32
SPE2 GigabitEthernet 1/0/0 VLANIF 40 100.1.2.2/24
GigabitEthernet 2/0/0 VLANIF 50 100.1.4.1/24
Loopback1 - 3.3.3.9/32
UPE2 GigabitEthernet 1/0/0 VLANIF 50 100.1.4.2/24
GigabitEthernet 2/0/0 VLANIF 60 -
Loopback1 - 5.5.5.9/32
CE1 GigabitEthernet 1/0/0 VLANIF 10 10.1.1.1/24
CE2 GigabitEthernet 1/0/0 VLANIF 60 10.1.1.2/24
Configuration Roadmap
The configuration roadmap is as follows:
1. Complete the task of Configuring Martini VPLS between SPEs.
2. Configure basic MPLS L2VPN functions on UPEs and SPEs.
3. Configure static VLLs and VSIs on SPEs and enable MAC-withdraw function on the VSIs.
4. Configure UPEs to access SPEs through static VLLs.
Data Preparation
To complete the configuration, you need the following data:
l Names and IDs of VSIs
l MPLS LSR IDs of UPEs and SPEs, which are used as peer IP addresses
l Routing protocol
l Received and sent labels on static LSPs between UPEs and SPEs
Procedure
1. Configure IP addresses for interfaces.
As shown in Figure 6-8, configure the VLAN to which each interface belongs, and
configure the IP addresses and masks for loopback interfaces and VLANIF interfaces.
NOTE
Do not add the AC-side port and PW-side port of a PE to the same VLAN; otherwise, a loop may
occur.
The S9300 only allows the CE to access the PE through a trunk.
2. Configure an IGP.
Configure OSPF on SPEs and the P device to advertise the network segment and LSR IDs.
