6 Activating the «clock» key.
Activating/deactivating the check box
Check box Check box for reset Status
☑ ☒ activated
☐ ☐ deactivated
Tab. 1 Check box status
Precondition Password level 2 is activated.
The display shows the operating mode.
Select the clock compressor menu
1. Press «Enter».
The main menu is displayed.
2. Select < Compressor clock > .
The display for setting the Compressor clock timing program appears.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
6 Compressor clock
Menu
Key clock: ☐
Reset: ☐
·········
01 n.a. 00:00 off
Enter switching point 01 (active line)
02 n.a. 00:00 off
Enter switching point 02
03 n.a. 00:00 off
Enter switching point 03
Entering switching points
1. Press «Enter» to switch into setting mode.
The n.a. column flashes in the active line.
2. Use «UP» to specify the settings for the weekdays.
3. Press «Enter» to accept the setting.
4. Press the «Right» key once.
5. Press «Enter» to switch into setting mode.
Column time, hours display, 00 : 00 flashes in the active line.
6. Use «UP» to specify the settings for the hours.
7. Press the «Right» key once.
Column time, hours display, 00 : 00 flashes in the active line.
8. Use «UP» to specify the settings for the minutes.
6 Activating the «clock» key.
