C o m p r e s s o r
Machine model
PN : SN :
Part number and serial number of the machine
EN :
Equipment number of the machine
SIGMA CONTROL 2 MCS
MCS: Main Control System
PN : SN :
Part number and serial number of the controller
Software :
Software version
Subsequently, the software is loaded and the current operating mode is displayed (example):
8 9 p s i 0 8 : 1 5 1 7 6 ° F
------------------------------
Alarm
Current operating mode
------------------------------
Key – off ¦ # – off
Operating parameters
------------------------------
Run 2500 h ¦ Load 2490 h
Operating parameters
Maintenance in 500 h
The following parameters are displayed:
■ Operating mode of the machine
■ Information on the «LOAD/IDLE» keys, «Remote control» or «Timer»
■ Value for the system setpoint pressure pA
■ Number of operating hours and hours of the machine being in LOAD mode.
The operations menu provides the most important parameters during the machine's operation.
4.6.2 Menu structure
Pressing «Enter» or one of the arrow keys opens the main menu.
In the main menu, you can:
■ Retrieve displayed information
■ Enter customer-specific settings
The menus shown require Access level 2.
4 Design and Function
4.6 Menus – overview
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
19
