7.11.2.2 Editing sensor designation and unit of measure
The display shows the line for the sensor designation as the active line.
1. Press «Enter» to switch into setting mode.
2. Use the «UP» and «DOWN» keys to select characters from the character set in order to assign
a name to the sensor signal. There are 20 characters to choose from.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.2.2.5 AI_I_1
Menu
Flow rate
The line for sensor designation
AII 1.02 ☐ 0
·········
20mA : 16000
4mA : 0
3. Press «Enter» to accept the setting.
4. Press «DOWN» once.
5. Press the «Right» key twice.
6. Press «Enter» to switch into setting mode.
The Unit display of the sensor flashes.
7. Use the «UP» and «DOWN» keys to select characters from the character set in order to assign
the unit to the sensor signal.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.2.2.5 AI_I_1
Menu
Volume flow 01.
The line for sensor designation
AII 1.02 ☐ 0 m3/h
Unit of measure
·········
20mA : 16000
4mA: 0
8. Press «Enter» to accept the setting.
Result Editing sensor designation and unit of measure.
7.11.2.3 Assigning the analog input
1. Press «left» twice, until AII 1.02 is displayed.
2. Press «Enter» to switch into setting mode.
The display of the analog input flashes.
3. Use «UP» to select AII 1.03 .
7 Initial Start-up
7.11 Configuring input and output signals
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
127
