KAESER ESD.2C - Example of a Machine ON;OFF Timer Program; Setting the Clock Program (Example)

2. Select < Compressor clock > .
The display for setting the Compressor clock timing program appears.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
6 Compressor clock
Menu
Key clock : ☐
Compressor clock is activated
Reset: ☐
All current switching points are reset
·········
01 n.a. 00:00 off
Active line
02 n.a. 00:00 off
03 n.a. 00:00 off
7.5.1.2 Setting the clock program (example)
When setting a timer program for the first time, note the switching times on a sheet of paper
first.
In addition to individual week days, the controller has the following cycles:
■ Mon-Thu
■ Mon-Fri
■ Mon-Sat
■ Mon-Sun
■ Sat-Thu
You can also program an OFF time (shutdown periods) (see section 7.5.2).
Example:
■ Machine ON: Weekdays 6:30 – 17:00, Fridays 6:30 – 15:00.
■ Machine OFF: Sat – Sun and during midday break from 12:00 – 13:00.
The following switching points result:
No. Day Time Function
1 Mon-Fri 06:30 ON
2 Mon-Fri 12:00 OFF
3 Mon-Fri 13:00 ON
4 Mon-Thu 17:00 OFF
5 Fri 15:00 OFF
Tab. 58 Example of a machine ON/OFF timer program
Precondition Password level 2 is activated,
the «Clock» key is activated,
the "clock" menu is selected.
