1. Press «DOWN» repeatedly until the
01 switching point
is displayed as the active line.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
6 Compressor clock
Menu
·········
01 n.a. 00:00 off
Active line with switching point 01
02 n.a. 00:00 off
Switching point 02:
03 n.a. 00:00 off
Switching point 03:
04 n.a. 00:00 off
Switching point 04:
05 n.a. 00:00 off
Switching point 05:
2. Press «Enter» to switch into setting mode.
The
n.a.
column flashes in the active line.
3. Use «UP» to specify the settings for the weekdays.
4. Press «Enter» to accept the setting.
5. Press the «Right» key once.
6. Press «Enter» to switch into setting mode.
The column time, display for hours,
00: 00
in the active line flashes.
7. Use «UP» to specify the settings for the hours.
8. Press the «Right» key once.
9. The column time, display for minutes,
00:
00
in the active line flashes.
10. Use «UP» to specify the settings for the minutes.
11. Press «Enter» to accept the settings.
The display stops flashing and the time (hours/minutes) is set.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
6 Compressor clock
Menu
·········
01 Mon-Fri 06:30 on
Switching point 01 is set
02 Mon-Fri 12:00 off
Switching point 02 is set
03 Mon-Fri 13:00 on
Switching point 03 is set
04 Mon-Thu 17:00 off
Switching point 04 is set
05 Fri 15:00 off
Switching point 05 is set
12. Press the «Right» key once.
The
Action on/off
column flashes.
13. Press «Enter» to switch into setting mode.
14. Use «UP» to specify the settings for the action Compressor ON.
15. Press «Enter» to accept the setting.
The Compressor ON function is set for the first switching point.
16. Specify further switching points in the same manner.
Result Weekdays, time, and the Compressor ON/Compressor OFF functions are set for all switching
points.
7 Initial Start-up
7.5 Configuring machine start and stop
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
67
