■ Assign and activate the input
■ Set the time delay
■ Set the logic
■ Assign and activate the output
■ Select the message type (operational, fault, warning)
■ Activate the message.
7.11.3.1 Selecting the < External messages > menu
Precondition Access level 2 is activated,
The electrical connections are made.
1. In operating mode, switch to the main menu with the «Enter» key.
2. Select < Configuration ➙ I/O periphery ➙ External messages > (see Section 7.11.1.1)
The External messages menu is displayed.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.3 External messages
Menu
▶1 External message 1
Active line with external message No. 1
▶2 External message 2
▶3 External message 3
▶4 External message 4
▶5 External message 5
▶6 External message 6
7.11.3.2 Entering the message text
External message 1 is shown as example.
1. Press «Enter».
External message 1 is displayed as the active line.
2. Press «Enter» to switch into setting mode.
The display of the character set flashes.
3. Enter the individual message text.
4. Press «Enter» to accept the setting.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.3.1 External message 1
Menu
External message 1
Message number
DI 1.11 ☐
No input assigned
td : 0 s ¦ Logic +
Logic
DOR 1.04 ☐
Warning ☑
Message type (operational, alarm, warning)
7.11.3.3 Assign and activate the input
1. Press «DOWN» repeatedly until "Input" is displayed as the active line.
