KAESER ESD.2C - Closing KAESER CONNECT; Performing a Data Backup

7.3.8 Performing a data backup
In order to use KAESER CONNECT to easily back up data from the SIGMA CONTROL 2 to your
own PC, use the <Data backup> menu.
You can choose to either perform a full backup or partial backups:
■ Full
■ Log files
■ Settings
■ User data
Precondition KAESER CONNECT for SIGMA CONTROL 2 is displayed.
1. Open the <Data backup> menu.
The system displays the <Data backup> menu.
Fig. 23 Data backup
1 <Data backup> menu
2 Selection
3 «Data backup» key
2. Select 2 .
3. Click the «Data backup» 3 key.
Result Data is saved to your PC.
7.3.9 Closing KAESER CONNECT:
To close KAESER CONNECT for SIGMA CONTROL 2, click Logout 3 in the header.
