Precondition Password level 2 is activated.
QUADRO control mode is selected.
The display shows the operating mode.
1. Press «Enter».
The main menu is displayed.
2. Select the < Configuration ➙ Control mode ➙ QUADRO > menu.
3. Press «DOWN» repeatedly until Target is displayed as the active line.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.3.3 QUADRO
Menu
Min. run period
Target 240 s ¦ Actual 0 s
Active line setpoint value for minimum run-time
·········
Unloaded period
Target 240 s ¦ Actual 100 s
4. Press «Enter» to switch into setting mode.
The setpoint value 240 s flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.3.3 QUADRO
Menu
Min. run period
Target 260 s ¦ Actual 0 s
Active line with changed setpoint value for minimum
run-time
·········
Unloaded period
Target 260 s ¦ Actual 100 s
Changed setpoint value for unloaded period
5. Use «UP» to change the minimum run-time.
6. Press «Enter» to accept the setting.
7. Change the unloaded period accordingly.
8. Press «Esc» repeatedly to return to the Main Menu.
Further information See chapter 4.7 for an overview of the control modes.
7.7 Activating the settings for the refrigerated dryer
Overview:
■ Set the operating mode
■ Output messages
7 Initial Start-up
7.7 Activating the settings for the refrigerated dryer
