Setting the LOAD remote contact operating mode
Precondition Access level 2 is activated.
The < Configuration ➙ Pressure control ➙ Load control > menu is selected.
1. Press «DOWN» repeatedly until Remote mode is displayed as the active line.
2. Press «Enter» to switch into setting mode.
Remote mode flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
·········
Remote mode : Load RC
Active line
Key remote : ☐
·········
▶1 pA/pB Clock
·········
3. Use «UP» to select the Load RC operating mode.
4. Press «Enter» to accept the setting.
Result The LOAD remote contact operating mode is set.
Assigning an input for the LOAD remote contact for switching the pressure control
1. Press «DOWN» repeatedly until Load RC is displayed as the active line.
2. Press «Enter» to switch into setting mode.
DI flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
·········
pA/pB RC DI 1.05 ☐
pA/pB DO DOR 1.04 ☐
·········
Load RC DI 1.13 ok ☑
Active line
loc.-load RC DI 1.09 ☐
3. Use «UP» to select a new input for LOAD remote contact.
4. Press «Enter» to accept the setting.
Result The input for LOAD remote contact is assigned.
7.9.7 Configuring setpoint pressure pre-selection via remote contact
The signal to changeover from setpoint pressure pA to setpoint pressure pB comes from an input
contact. If there is a signal at the input then system pressure is regulated on setpoint pressure pB.
Overview
■ Setting up remote contact mode pA/pB
