KAESER ESD.2C - Checklist of Installation Conditions; Commissioning the Machine

3. Press «Enter» to accept the setting.
Input AII (analog value via frequency converter) is displayed.
4. Press «DOWN» once.
The line for activating the input is displayed.
5. Press the «Right» key.
6. Press «Enter» to switch into setting mode.
The check box flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.4 Network actual pressure
AII 89 psi
AII 1.01 ok ☑ 89 psi
Active line
7. Press «UP».
8. Press «Enter» to accept the setting.
Result The input for the external transducer is now activated.
You have connected an external pressure transducer to a frequency converter (USS proto‐
col).
➤ Assign the input FC USS to the pressure transducer.
7.14 Commissioning the machine
Checking the controller settings Section Complied?
➤ Language correctly set? 7.2.2
➤ Date and time correct? 7.2.8
➤ Display format correctly set? 7.2.9
➤ System pressure setpoint correctly set? 7.4
Tab. 71 Checklist of installation conditions
