7.11.1 Outputting important operational states of the machine
Important operational machine states can be made available as a binary signal via floating con‐
tacts.
Each output can be assigned only once.
The following messages can be returned:
Message Explanation Output
Controller on Controller is powered up
Compressor on The machine is switched on.
Motor running Compressor motor running
IDLE The machine is running in IDLE mode
ON LOAD The machine is running in LOAD mode
Group alarm Fault has occurred
Group warning Warning message has appeared
Remote mode Remote mode is activated
Clock active The clock is activated
Clock contact The clock contact is closed.
EMERGENCY STOP The «EMERGENCY OFF» button has been pressed
Tab. 68 Assigned output signals
Overview
Navigate to the < Configuration ➙ I/O periphery ➙ DO functions > menu for the configuration:
■ Access level 2 is activated.
■ Assigning a message to an output
7.11.1.1 Selecting the < Configuration ➙ I/O periphery > menu
Precondition Access level 2 is activated.
1. In operating mode, switch to the main menu with the «Enter» key.
2. Select < Configuration ➙ I/O periphery ➙ DO functions > .
A list of available messages and their assigned outputs is displayed.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.1 DO functions
Menu
Controller on
Active line
DOR 1.05 ☐ ¦ Logic : +
DOT 1.02 ☐ ¦ Logic : +
Compressor on
DOR 1.03 ☐ ¦ Logic : +
DOT 1.02 ☐ ¦ Logic : +
7.11.1.2 Assigning a message to an output
1. Select the required message with the «DOWN» key.
7 Initial Start-up
7.11 Configuring input and output signals
124
