Further setting options:
■ SMTP port
■ Timeout
■ Interval (repeats)
Result The email functions are configured and activated.
Suppress repeat messages (setting an interval)
To suppress messages repeating at short intervals, a period of 0 – 900 minutes can be set during
which a repeat of the same message is suppressed, i.e. is not sent.
Precondition Password level 2 is activated.
E-mail
submenu is displayed as being active.
1. Press «Enter».
2. Press «DOWN» repeatedly until
Interval:
is displayed as the active line.
3. Press «Enter» to switch into setting mode.
The
value
for the time of suppression flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
8.1.3 E-mail
Menu
Password
·········
Port 25 ¦ Timeout 10 s
Interval: 5 min
Active line
4. Use the «UP» or «DOWN» keys to set the desired duration of suppression.
5. Press «Enter» to accept the setting.
6. Press «Escape» repeatedly to return to the main menu.
Result Suppression interval is set.
7.11 Configuring input and output signals
The controller's binary and analog inputs and outputs can be used for other requirements.
This chapter deals with the various options in the following sections:
■ 7.11.1: Outputting important operational states of the compressors.
■ 7.11.2: Displaying analog input values
■ 7.11.3: Displaying additional binary input signals
The controller only allows assignment of spare inputs and outputs.
Any assignment of a preassigned input or output is discarded by the controller.
When delivered from the factory, the outputs DO0.3 to DO0.5 are available for assignment.
Further spare outputs can be found in the machine circuit diagram.
➤ Configure the inputs and outputs as described in the following.
7 Initial Start-up
7.11 Configuring input and output signals
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
123
