KAESER ESD.2C - Fig. 6 Machine Mountings; Fig. 7 Cooling Air Filter Mat (Option K3)

4.5 Options
The options available for your machine are described below.
4.5.1 Option K2/K9
Water cooling
Stainless steel plate-type heat exchanger (Option K2) or bundled pipe heat exchangers (Option
K9) are used in machines with water cooling.
4.5.2 Option H1
Machine mountings
These mountings allow the machine to be anchored firmly to the floor.
Fig. 6 Machine mountings
4.5.3 Option K3
Cooling air filter mat
The mat filters the cooling air and keeps the cooler surface clean.
Fig. 7 Cooling air filter mat (option K3)
1 Cooling air filter mat
