Set local/LOAD remote contact operating mode:
1. Press «UP» repeatedly until Remote mode is displayed as the active line.
2. Press «Enter» to switch into setting mode.
Remote mode flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
·········
Remote mode : loc.-load RC
Active line, current operating mode
Key remote : ☐
·········
current pA
3. Use «UP» to select the loc.-load RC operating mode.
4. Press «Enter» to accept the setting.
Result The local/LOAD remote contact operating mode is set.
Assigning an input for the local/LOAD remote contact for switching the pressure control
1. Press «DOWN» repeatedly until loc.-load RC is displayed as the active line.
2. Press «Enter» to switch into setting mode.
DI flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
pA/pB DO DOR 1.04 ☐
No input assigned
·········
Load RC DI 1.13 ok ☑
loc.-load RC DI 1.09 ok ☑
Active line
·········
Key idle : ☑
3. Use «UP» to select a new input for local/LOAD remote contact.
4. Press «Enter» to accept the setting.
Result The input for local/LOAD remote contact operating mode is assigned.
7.9.6.3 Setting local operating mode pB
System setpoint pressure pB is normally set for local operation.
➤ When setting the system setpoint pressure pB, bear in mind that, under certain circum‐
stances, more than one compressor may be operating in local mode (see section 7.4 for
adjusting the system setpoint pressure).
Precondition Access level 2 is activated.
The < Configuration ➙ Pressure control ➙ Load control > menu is selected.
1. Press «UP» repeatedly until Local mode is displayed as the active line.
