KAESER ESD.2C - Adjusting the Idle Time of DUAL Mode; Adjusting the Minimum Running and Unloaded Period in QUADRO Control

7.6.2 Adjusting the idle time of DUAL mode
The machine is READY when the specified idle time has elapsed.
The shorter the period, the more often the machine will switch from IDLE to READY.
SIGMA CONTROL 2 will take into account the maximum motor switching capacity.
Depending on the machine type, the machine's motor may not fall below a minimum idling or
standstill time.
Precondition Password level 2 is activated.
The control mode is selected.
The display shows the operating mode.
1. Press «Enter».
The main menu is displayed.
2. Select the < Configuration ➙ Control mode ➙ DUAL > menu. (See section 7.6.1)
The setting for idle time is shown in the active line.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.3.2 DUAL
Menu
Idle period
Target 240 s ¦ Actual 0 s
Active line
3. Press «Enter» to switch into setting mode.
The current idle time of 240 s flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.3.2 DUAL
Menu
Idle period
Target 300 s ¦ Actual 0 s
Active line with changed idle time, (example: 300
seconds)
4. Use «UP» to change to the desired idle time.
5. Press «Enter» to accept the setting.
6. Press «Esc» repeatedly to return to the Main Menu.
7.6.3 Adjusting the minimum running and unloaded period in QUADRO control
mode
When the minimum running period has elapsed, the machine switches from IDLE to READY. De‐
pending on the setting for the unloaded period, the machine switches first from LOAD to IDLE or
directly to READY.
