7.11.3.5 Setting the logic
Possible logic settings
Message at Symbol
24 V +
0 V -
Tab. 69 Logic
1. Press the «Right» key once.
2. Press «Enter» to switch into the logic setting mode.
The
Logic
display flashes.
3. Use «UP» to set the desired behavior, see table 69.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.3.1 External message 1
Menu
External message 1
DI 1.11 ok ☑
td : 1 s ¦ Logic +
Active line, set logic
DOR 1.04 ☐
Alarm ☑
Example: Fault message type
4. Press «Enter» to accept the setting.
For messages at 24 V, the logic is set with the + symbol.
7.11.3.6 Assign and activate the output
1. Press «DOWN» repeatedly until "Output" is displayed as the active line.
2. Press «Enter» to switch into setting mode.
The Output display flashes.
3. Select the output with the «UP» or «DOWN» keys.
4. Press «Enter» to accept the setting.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.3.1 External message 1
Menu
External message 1
Message name
DI 1.11 ok ☑
td : 1 s ¦ Logic +
Logic
DOR 1.04 ok ☑
Output is selected and activated
Alarm ☑
Example: Fault message type
5. Press the «Right» key.
6. Press «Enter» to switch into setting mode.
The check box will flash.
7. Press «UP» to activate the check box.
