KAESER ESD.2C - Setting and Activating Summer;Winter Time; Using KAESER CONNECT

2. Press «DOWN» once until Mode is displayed as the active line.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.1 General
Menu
·········
Pressure unit bar
Temperature unit °C
·········
Display lighting
Mode: auto. ¦ Timeout : 1 min
Active line
3. Press «Enter» to switch into setting mode.
The on display flashes.
4. Use «UP» to select the auto. mode.
5. Press «Enter» to save the setting.
6. Enter the setting for time-out in the same manner.
7. Press «Enter» to save the setting.
8. Press «Esc» repeatedly to return to the Main Menu.
Result The display illumination is set for automatic operation with deactivation after one minute without
user intervention.
7.2.10 Setting and activating summer/winter time
The system automatically switches between summer and winter time.
7.3 Using KAESER CONNECT
Using a PC with web browser, KAESER CONNECT enables you to view the following of the
SIGMA CONTROL 2:
■ System status
■ Graphs
■ Messages
■ IO display
■ User administration
■ Settings
■ Data backup
Thus, KAESER CONNECT provides an excellent option for an easy and quick check of the energy
efficiency of your compressors.
The following functions are not available with KAESER CONNECT:
■ Remotely starting the machine
■ Remotely changing parameters
7 Initial Start-up
7.3 Using KAESER CONNECT
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
47
