2. Press «Enter» to switch into setting mode.
The display of the selected message flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.7.1 DO functions
Menu
Controller on
DOR 1.05 ok ☑ ¦ Logic : +
Active line with assigned output
DOT 1.02 ☐ ¦ Logic : +
Compressor on
DOR 1.03 ☐ ¦ Logic : +
DOT 1.02 ☐ ¦ Logic : +
3. Select a free output with the «UP» or «DOWN» key.
4. Press «Enter» to accept the setting.
5. Press the «Right» key.
6. Press «Enter» to switch into setting mode.
7. Activate the check box.
8. Press «Enter» to accept the setting.
If the message is correctly assigned to the output and activate,
ok
is displayed.
9. If necessary, set
Logic
.
A message is now sent via the assigned output.
You are missing an organized display of assigned output signals?
➤ Enter the selected output in table 68.
7.11.2 Displaying analog input values
The
< Performance data >
menu can display up to six values from analog measuring sensors of
pressure or temperature, for example.
Of these, two each are assigned to pressure and temperature transducers; two further inputs can
be assigned to freely selectable sensor types. A list of standard analog data that can be displayed
is found in chapter 8.7.
Overview
Navigate to the
< Configuration ➙ I/O periphery ➙ Analogue values >
menu for the configuration.
■ Select
< Configuration ➙ I/O periphery ➙ Analogue values >
.
■ Select display (display 1–6)
■ Edit sensor designation and unit of measure
■ Assigning the analog input
■ Selecting the type of signal (4–20 mA / 0–20 mA)
■ Assign a value range to the measurement signal (calibration)
Example:
The configuration is explained with the following example:
The signal value from a flow measuring device is to be displayed in the measured
<data menu>
.
■ Sensor designation: Volume flow 01.
■ The sensor is connected to analog input AII 1.03.
