4.3 Display
Use the display to read information and to enter data. The display comprises 8 lines, each of
30 characters.
During operation, the display will indicate the operating mode.
Pressing «Enter» or one the arrow keys opens the main menu. Here, you can set the language to
be used for the display of texts or open the various submenus.
4.3.1 Operating mode
8 9 p s i 0 8 : 1 5 1 7 6 ° F
------------------------------
Alarm
Current operating mode
------------------------------
Key – off ¦ # – off
Operating parameters
------------------------------
Run 2500 h ¦ Load 2490 h
Operating parameters
Maintenance in 500 h
Header
The header is the topmost line on the display. It is always shown as white text on a black back‐
ground.
The following parameters are displayed permanently on the title bar:
■ Working pressure
■ Time
■ Airend discharge temperature
Lines 3 and 5: Operational state
Depending on the settings, either the current state of the machine or a menu text is shown in line 3.
The following parameters with their current values are displayed in line 5:
■ Remote control: yes/no
■ Timer control: yes/no
■ Pressure control
Lines 7 and 8: Machine state
The following parameters with their current values are displayed in lines 7 and 8:
■ The hours during which the machine was activated
■ The hours during which the machine ran in operating mode LOAD.
■ Remaining working hours of the machine before the next maintenance
4 Design and Function
4.3 Display
14
Service manual Controller
