7. Press «Enter» to accept the settings.
The display stops flashing and the time (hours/minutes) is set.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3.1 pA/pB Clock
Weekday setting.
Reset: ☑
·········
01 Mon-Fri 06:30 pB
Active line, time, first switching point
02 Mon-Fri 17:00 pB
Time, second switching point
03 n.a. 00:00 pB
04 n.a. 00:00 pB
8. Enter the time for the second switching point in the same manner.
Result The times for the first two switching points are set.
Selecting the system setpoint pressure pA or pB for the first two switching points.
1. Press the «UP» key repeatedly until the switching point 01 is displayed as the active line.
2. Press the «Right» key twice.
The column for system setpoint pressure
pA
or
pB
is displayed.
3. Press «Enter» to switch into setting mode.
The column for the system setpoint pressure flashes.
4. Use «UP» to specify the settings for the system setpoint pressure pA or pB.
5. Press «Enter» to accept the settings.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3.1 pA/pB Clock
Weekday setting.
Reset: ☑
Current start time
·········
01 Mon-Fri 06:30 pA
System setpoint pressure for the first switching point
02 Mon-Fri 17:00 pB
System setpoint pressure for the second switching
point
03 n.a. 00:00 pB
04 n.a. 00:00 pB
6. Enter the system setpoint pressure for the second switching point in the same manner.
7. Press «Escape» repeatedly to return to the main menu.
Result Select the system setpoint pressure pA or system setpoint pressure pB for the first two switching
points.
Setting local mode
Precondition Access level 2 is activated.
1. Select the
< Configuration ➙ Pressure settings ➙ Load control >
menu.
The
Local mode
mode is displayed as the active line.
7 Initial Start-up
7.9 Configuring the machine for master control
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
119
