KAESER ESD.2C - Assigning an Input to an External Sensor; Selecting the < Configuration ➙ Pressure Control > Menu

7.13.1 Selecting the < Configuration ➙ Pressure control > menu
Precondition Access level 2 is activated.
1. In operating mode, switch to the main menu with the «Enter» key.
2. Select the < Configuration ➙ Pressure control > menu.
< Pressure settings > sub-menu line is displayed as the active line.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2 Pressure control
Menu
▶1 Pressure sensors
▶2 Pressure settings
Active line
▶3 Load control
▶4 Network actual pressure
3. Press «DOWN» twice.
< Network actual pressure > sub-menu is displayed as the active line.
4. Press «Enter».
The < Network actual pressure > menu is displayed.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.4 Network actual pressure
Menu
pNloc 89 psi
Active line (local sensor)
AII 1.01 ☐ 0 psi
7.13.2 Assigning an input to an external sensor
1. Press «Enter» to switch into setting mode.
pNloc flashes.
2. Press the «UP» key once.
The AII is displayed.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.4 Network actual pressure
AII 89 psi
Active line (external sensor)
AII 1.01 ☐ 0 psi
