2. Press «Enter» to switch into setting mode.
Setpoint pressure flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
Local mode pB
Active line, current operating mode
·········
Remote mode : loc.-load RC
Key remote : ☐
·········
current pB
3. Use «UP» to select the pB operating mode.
4. Press «Enter» to accept the setting.
5. Adjust the system setpoint pressure pB if necessary (see section 7.4).
Result The local operating mode pB is set.
7.9.6.4 Activating the «Remote control» key
Precondition Access level 2 is activated.
The < Configuration ➙ Pressure control ➙ Load control > menu is selected.
1. Press «UP» or «DOWN» repeatedly until Key remote is displayed as the active line.
2. Press «Enter» to switch into setting mode.
The check box for Key remote flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
·········
Remote mode : loc.-load RC
Key remote : ☑
Active line
·········
current pB
3. Use the «UP» key to activate the check box.
4. Press «Enter» to accept the setting.
The «Remote control» key is activated and can be used.
5. Press the «Remote control» key to enable remote mode.
Result The master control is fully configured.
7.9.6.5 Setting the LOAD remote contact operating mode and assigning the input
Precondition Access level 2 is activated.
The < Configuration ➙ Pressure control ➙ Load control > menu is selected.
