8.7 Displaying analog data
The following information can be called up in the
< Performance data >
menu option:
■ Local system pressure
■ Airend discharge temperature
Rise rate, airend discharge temperature
■ Differential pressure, oil separator cartridge
■ Start temperature, compressor motor
■ Temperature MCS ( SIGMA CONTROL 2 )
■ Temperature, first IOM
The data for the actual pressure can be displayed in
< Configuration ➙ Pressure control ➙
Network actual pressure >
.
Displaying analog data
Precondition Password level 2 is activated.
The display shows the operating mode.
1. In operating mode, switch to the main menu with the «Enter» key.
2. Select the
< Performance data >
menu.
An overview of the analog data is displayed.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
2 Performance data
Menu
System pressure pNloc 89 psi
Local System pressure pNloc
·········
ADT T 176 °F
Airend discharge temperature
dT/dt 32 °F /s
Increase of airend discharge temperature
Oil separator Δp 0 psi
Differential pressure, oil separator cartridge
·········
3. Press «DOWN» to display additional analog data.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
2 Performance data
Menu
·········
Starting temperature 32 °F
Temperature of compressor motor
·········
·········
MCS T 98 °F
Temperature of the controller (Main Control System)
First IOM T 32 °F
Temperature, first I/O module
4. Press «Esc» repeatedly to return to the Main Menu.
8 Operation
8.7 Displaying analog data
9_9450 03USE
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3
147
