2. Press «Enter» to switch into setting mode.
Setpoint pressure pA flashes.
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.2 Pressure settings
Menu
Setpoint pressure
pA SP : 124 psi ¦ SD : - 7 psi
Active line
pB SP : 119 psi ¦ SD : - 7 psi
·········
System pressure low
↓ < 73 psi ¦ SD : 7 psi
:
3. Use «UP» or «DOWN» to adjust the value.
4. Press «Enter» to accept the setting.
5. Adjust the switching differential pA in the same manner.
6. If necessary, adjust the value for pB in the same way.
7. Press «Esc» repeatedly to return to the Main Menu.
Configuring local mode
➤ Set the clock program or clock as described in section 7.8.
Assigning the floating relay contact (activate)
Precondition Access level 2 is activated.
The electrical connection made (select spare contact from the machine's electrical diagram).
1. Select < Configuration ➙ Pressure control ➙ Load control > .
2. Press the «DOWN» key repeatedly until the following is displayed as the active line:
8 9 p s i 0 8 : 1 5 1 7 6 ° F
5.2.3 Load control
Menu
·········
pA/pB RC DI 1.10 ☐
pA/pB DO DOR 1.03 ☐
Active line, no output assigned
·········
3. Press «Enter» to switch into setting mode.
Output display flashes.
4. Use «DOWN» or «UP» to select the required output (DOR).
5. Press «Enter» to accept the setting.
This output can now be used for the changeover between the two pressure switches.
Setting local mode
Precondition Access level 2 is activated.
1. Select the < Configuration ➙ Pressure control ➙ Load control > menu.
7 Initial Start-up
7.9 Configuring the machine for master control
114
