7. Press «Enter» to accept the setting.
The Offset display changes to 95°F .
The Airend discharge temperature ADT ⇞ display changes to 226°F .
The test mode is now activated.
8 9 p s i 0 8 : 1 5 1 6 3 ° F
9.1 TÜV inspection
Menu
·········
Airend discharge temperature ADT
⇞ : ☑
Active line
Offset : 35 °C ¦ ADT ⇞ 108 °C
Offset, airend discharge temperature in test mode
Reset: ☐
8. Press the «ON» key to switch the machine to LOAD.
The machine switches to LOAD and the airend discharge temperature rises again.
The machine will switch off as soon as the airend discharge temperature attains a value of
226°F .
The machine does not shut down?
➤ Abort the test and contact KAESER Service as soon as possible.
Correct conclusion of the test
1. Press «Enter» to switch into setting mode.
The check box in the active line flashes.
2. Use the «DOWN» key to deactivate the check box.
3. Press «Enter» to accept the setting.
The offset is reset to 32°F .
The test mode is deactivated and the test is completed.
4. Press «Esc» repeatedly to return to the main menu.
Resetting
SIGMA CONTROL 2 will display the highest measured value if the test for switching off at overtem‐
perature is aborted.
Activate the Reset check box in order to reset the stored value.
➤ Activate the Reset check box.
Further information See chapter 8.11 for testing the temperature sensor.
