Input/Output Input/output module 1
Internal, into
the control
cabinet
available in
parallel on
both sides
External, into
the compres‐
sor interior
Analog output current (AOI), 0–20 mA – – –
Tab. 14 SC2IOM-1
IOM 2
Input/Output Input/output module 2
Internal, into
the control
cabinet
available in
parallel on
both sides
External, into
the compres‐
sor interior
Digital input (DI), 24 VDC 6 – 2
Analog input current (AII), 0–20 mA – 1 2
Analog input resistor (AIR), PT100 – 3 –
Digital output relay (DOR), 250 VAC, 8 A 4 – –
Digital output transistor (DOT), 24 VDC, 0.5 A – 2 2
Analog output current (AOI), 0–20 mA – 1 –
Tab. 15 SC2IOM-2
IOM 3
Input/Output Input/output module 3
Internal, into
the control
cabinet
available in
parallel on
both sides
External, into
the compres‐
sor interior
Digital input (DI), 24 VDC 6 – 2
Analog input current (AII), 0–20 mA – 1 3
Analog input resistor (AIR), PT100 – 3 8
Digital output relay (DOR), 250 VAC, 8 A 8 – –
Digital output transistor (DOT), 24 VDC, 0.5 A – 1 1
Analog output current (AOI), 0–20 mA – 1 –
Tab. 16 SC2IOM-3
2.1.2.1 Power supply specifications
Power is provided by the power supply unit within the machine.
Feature Value
Rated power supply (stabilized) [V DC] 24
Current consumption SIGMA CONTROL 2
with IOM 1 [A]
2,4
Current consumption IOM 2 [A] 2,5
IOM ≙ input/output module
2 Technical Data
2.1 SIGMA CONTROL 2 Controller
6
Service manual Controller
SIGMA CONTROL 2 SCREW FLUID 1.1.3 9_9450 03USE
