3. Press «Enter» to open the submenu.

The system information is displayed.

8 9 p s i 0 8 : 1 5 1 7 6 ° F

5.1.1.1 SIGMA CONTROL 2 MCS

Software 1.1.3

Software

·········

Kaeser

PN 7.7601.0

Part number

SN x.xx.xx

Serial number

·········

4. Keep pressing the «DOWN» key to display further settings.

8 9 p s i 0 8 : 1 5 1 7 6 ° F

5.1.1.1 SIGMA CONTROL 2 MCS

SN x.xx.xx

·········

Prodrive

Manufacturer

PN 6309.1000.7900

Part number

SN 10.34.000.961

Serial number

MFGDT 2010/08

Manufacturing date
