Page 108 Job Editor Group 8
Release R1.06 JET3up
Printstyle (5)
<Print height>
Default (80%)
<Orientation>
Default (0°)
<mirrored>
Default (no)
PrintGo Parameter (6)
<PrintGo Distance>
Not available for
<Extern Joblist>
. This para-
meter can be defined within each print job. It will
only affect print jobs with repetitions.
<PrintGo Repeat>
Not available for <Extern Joblist>. This para-
meter can be defined within each print job.
Distances between repetitions are defined with
the <PrintGo Distance>
parameter within the
print job.
<endless>
Not available for
<Extern Joblist>
This para-
meter can be defined within each print job.
<PrintGo Source>
<Extern> and <positive edge>.
<PrintStop interrupts print-
out immediately>
Default (no)
<PrintGo Gate>
Default (no)
Encoder Parameter (7)
<Encoder Source>
Extern
<Resolution>
12.500
<intern Speed>
Not available if an external encoder is used
<Encoder/Direction>
Clockwise
<Speed dependent output>
Not used. Default (700)
<lock backward>
yes
Date Change Parameter (8)
<Date Change Offset>
Default (0)
6. Save the created job list (9-10).
7. Open the job list with the <Load Joblist to print> (11-12).
8. Get the printer ready to print (open nozzle seal, push green <PrintStart>
button).
9.
Apply the address of the print job at the first position of the job list to the
X4 connector (decimal=1; 10-bit binary=0000000001) (13).
10. With the next <PrintGo> signal the addressed print job will be printed.
11.
Apply the address of the print job at the seventh position of the job list to
the X4 connector (decimal=7; 10-bit binary=0000000111) (13).
12. With the next <PrintGo>signal the addressed print job will be printed.
13.
Apply the address of the print job at the fifth position of the job list to the
X4 connector (decimal=5; 10-bit binary=0000000101 (13).
14. With the next <PrintGo> signal the addressed print job will be printed.
