Page 284 Job Editor Group 8
Release R1.06 JET3up
Example2
Settings:
PrintGo repeat: endless
Rotational direction: right
Use encoder direction for mirror: activated
Normally the printout would be mirrored if the print direction is changed from
forward to backward (1). With the option <Use encoder direction for mirror>
the
printout will be mirrored a second time in order to get a proper printout (2).
Use encoder direction for mirror :
Not activated
Use encoder direction for mirror :
activated
Printhead
(Top view)
Printing direction
Printing direction
Printing direction
Printing direction
Printhead
(Top view)
1
2
Printhead
(Top view)
Printhead
(Top view)
