Group 8 Job Editor Page 337
JET3up Release R1.06
Example for <Character offset> and <Wildcards>:
Set wildcards:
X
X
X
Set offset:
3
Display in the print preview of the main window as long as there were no data
received:
XXX
Received data:
1
2
3
4
5
6
7
8
Used data (regarding the offset (O) and the wildcards (W)):
1 (O)
2 (O)
3 (O)
4 (W)
5 (W)
6 (W)
7 (W)
8 (W)
Display of the received data in the print preview of the main window:
456
Result:
Due to the set offset the first 3 characters of the received character string will not
be used. Due to the wildcards only the first 4 characters of the remaining character
string are used.
