Page 340 Job Editor Group 8
Release R1.06 JET3up
Example print-out:
This example is based on a print job with three <Extern Text: fixed length>
objects. Each object has different settings for wildcards and offset
OS). The character string 12ab345 sha
ll be transmitted. The settings for each
<Extern Text: fixed length> object look as follows:
Object 1:
Wildcards: X
Offset: 0 0 offset
Sum of wildcards and offset: 1
Object 2:
Wildcards: YY
Offset: 1 1 offset
Sum of wildcards and offset: 3
Object 3:
Wildcards: ZZZ 3 wildcard
Offset: 3 3 offset
Sum of wildcards and offset: 6
The input buffer in this example has the length of 6 characters because the largest
sum of wildcards and offset is 6.
Beside the inp
ut buffer there is also a display buffer. The content of the display
buffer is what you see in the print preview of the main window of the JET3up
printer.
There are three rules regarding the input and the display buffer:
1. The input buffer has to be complet
ely filled before its content is transferred
to the display buffer.
2. The print-
out always reflects the content of the display buffer (what you see
is what you get printed).
3.
The input buffer is emptied as soon as its content is transferred to the
display buffer.
