Lexmark T65 Series Service Manual

4-72 Service Manual
7462
Go Back
Previous
Next
5. Remove the two screws (C) securing the ADF transport drive motor bracket assembly with cable to the
ADF feed motor bracket.
6. Slide the ADF transport drive motor bracket to the right, loosening the transport belt.
7. Remove ADF transport drive motor bracket assembly with cable.
C B A

Lexmark T65 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Print Technology	Laser
Standard Paper Capacity	650 sheets
Connectivity	USB, Ethernet
Operating Systems Supported	Windows, Linux
Maximum Paper Size	8.5 x 14 inches
