4-114 Service Manual

7462

Go Back

6. Remove eight screws (E) securing the scanner controller cage cover to the cage. An X658 model is

represented in the graphic below, however, the card cage cover removal procedure is similar for all

models.

7. Remove the printer controller card cage cover.

8. Disconnect the USB cable and the cover closed interlock switch harness.
