4-180 Service Manual

7462

Go Back

Media size actuator removal

Note: Carefully remove the base machine from the input option tray assembly before proceeding.

1. Remove the 250-sheet controller card assembly. Go to “250-sheet controller card assembly removal”

on page 4-178.

2. Remove the screw (A) securing the media size actuator to the 250-sheet frame.

3. Remove the media size actuator.
