Repair information 4-219
7462
4-bin mailbox assembly controller card assembly removal
1. Remove the 4-bin mailbox assembly left cover. See “4-bin mailbox assembly left cover removal” on
page 4-218.
2. Disconnect all harnesses from the controller card.
Note: Label each deflector gate solenoid cable for correct replacement upon installation.
3. Remove the two screws (A) securing the controller card to the 4-bin mailbox assembly and remove.
To Next Page
