4-230 Service Manual

7462

Go Back

4-bin mailbox assembly deflector gate (bin 4) removal

1. Remove the 4-bin mailbox assembly rear door assembly. See “4-bin mailbox assembly rear door

assembly removal” on page 4-222.

2. Grasp the 4th bin deflector gate and pull out on either side.
