Repair information 4-229
7462
4-bin mailbox assembly deflector gate (bin 1 through 3) removal
1. Remove the 4-bin mailbox assembly rear door assembly. See “4-bin mailbox assembly rear door
assembly removal” on page 4-222.
2. Remove the 4-bin mailbox assembly right rear inner cover.
3. Remove the 4-bin mailbox assembly spring. See “4-bin mailbox assembly spring removal” on
page 4-228.
4. Grasp the deflector gate and pull it out of its socket on each side. Carefully remove the diverter from the
machine.
