LSIS XGT Series User Manual

Chapter 6 Motion Function Blocks
6-13
NO. Name Description
Operation
condition
Coordinate system command
64
MC_SetKinTransform
Machine information setting
Edge
65
MC_SetCartesianTransform
PCS setting
Edge
66
LS_SetWorkSpaceTransform
Work space setting
Edge
67 LS_MoveLinearTimeAbsolute
Time- linear interpolation operation for absolute position
of coordinate system
Edge
68 LS_MoveLinearTimeRelative
Time- linear interpolation operation for relative position of
coordinate system
Edge
69 MC_MoveCircularAbsolute2D
Circular interpolation operation for absolute position of
coordinate system
Edge
70 MC_MoveCircularRelative2D
Circular interpolation operation for relative position of
coordinate system
Edge
71
MC_TrackConveyorBelt
Synchronization setting of the conveyor belt
Edge
72 MC_TrackRotary table Synchronization setting of the rotary table Edge
73
LS_RobotJOG
JOG operation of the coordinate system
Level
74 LS_SetMovePath Set path operation data Edge
75
LS_ResetMovePath
Delete path operation data
Edge
76
LS_GetMovePath
Read path operation data
Edge
77
LS_RunMovePath
Perform path operation
Edge
NC control command
78 NC_LoadProgram Specify NC program Edge
79
NC_BlockControl
Specify Block operation
Level
80
NC_Reset
Reset
Edge
81
NC_Emergency
Emergency stop
Level
82 NC_CycleStart Start automatic operation Edge
83
NC_FeedHold
Feed Hold
Level
84
NC_Home
Homing
Edge
85
NC_RapidTraverseOverride
Rapid traverse override
Level
86 NC_CuttingFeedOverride Cutting feed override Level
87
NC_SpindleOverride
Spindle override
Level
88
NC_M codeComplete
M Code operation completed
Edge
89
NC_ScodeComplete
S Code operation completed
Edge
90 NC_TcodeComplete T Code operation completed Edge
91
NC_ReadParameter
Read NC parameters
Level
92
NC_WriteParameter
Write NC parameters
Edge
