Chapter 9 NC Control Function
9-64
Parameters
Group
No.
Item
Description
1. Channel
parameters
1. Basic
setting
20
Whether to use the 3rd
„No Travelling Area‟
0: „No Travelling Area‟ is valid.
1: „No Travelling Area‟ is invalid.
22
Rotary axis of Cylindrical
interpolation
In the cylindrical interpolation mode, the axis maps
the axis of rotation during the circular
interpolation.The axes are X, Y, Z and perform the
circular interpolation by mapping the axis of rotation
to the selected axis.
For example, if the axis of rotation is mapped to the
X axis under the state of the XY plane (G17), the
width becomes the axis of rotation and the height
becomes Y axis. When ZX (G18) is selected as the
plane, the width becomes the Z axis and the height
becomes the axis of rotation. However, if you set the
plane to YZ (G19), you cannot perform the circular
interpolation on the commanded axis of rotation.
0: X-axis,
1: Y-axis,
2: Z-axis
23
Linear axis for
interpolating the polar
coordinate
0: Unused
1: X, 2: Y, 3: Z, 4: A, 5: B, 6: C, 7: U, 8: V, 9: W
24
Rotary axis for
interpolating the polar
coordinate
0: Unused
1: X, 2: Y, 3: Z, 4: A, 5: B, 6: C, 7: U, 8: V, 9: W
33
Monitoring time for in-
position completion
0 ~ 65,535ms
