Chapter 9 NC Control Function
Select a progress block at
reset
Set whether to initialize to the start block of the
program at reset.
※ If you want to set to 0 (keep the current block), the
parameters of "Keep workpiece coordinate system"
should be set to 0 (keep).
0: Keep the current block
1: Initialize to the start block of the main program
2: Initialize to the current block of the main program
Whether or not to search
the Statement Number
The number of buffers that can store the program‟s
Statement Number (N__) is limited to 1,000 in the
system.
This buffer is needed if the program changes the
sequence using a GOTO statement.
If more than 1,000 blocks have the N__ command,
an alarm will occur.
This parameter is used to input whether or not to
execute such Statement Number search.
Because high- capacity CAM programs do not have
GOTO using the Statement Number and in the
majority of cases, there are more than 1,000
Statement Numbers, you should set this parameter
as 1.
0: Search
1: Do not search
When decimal point check is applied, set the
minimum unit of the commanded value.
(0 ~ 0.999mm)
Whether to use G22 No
Travelling Area
0: „No Travelling Area‟ is valid.
1: „No Travelling Area‟ is invalid.
Set the inner/outer side of
G22 No Travelling Area
0: Inner side
1: Outer side
