Figure 5.13: Header on Flat Deck
5. Remove hauler’s tie-down straps and chains.
6. Slowly raise both forklifts until header clears the trailer
deck by 102– 204 mm (4–8 in.).
7. Slowly drive truck forward until trailer is clear of header.
8. Place 150 mm (6 in.) blocks under each end of cutterbar.
9. Lower header onto blocks.
10. Slowly back forklifts away from header.
11. Check for shipping damage and missing parts.
1008297
A
B
Figure 5.14: Raised Header Stand
12. Lower header stand (B) by pulling pin (A), lowering the
stand, and releasing the pin to secure the stand in place.
13. Place 150 mm (6 in.) blocks under each end of cutterbar.
14. Lower header onto blocks and header stand.
NOTE:
If ground is soft, place a block under the stand.
15. Slowly back forklifts away from header.
16. Check for shipping damage and missing parts.
17. Proceed to 5.6 Removing the Remaining Shipping Supports, page 163 .
UNLOADING HEADER AT DEALER
