Chapter 12: Reference
12.1 Parts List
This list includes parts that are bagged and attached to 12.2 and 13.7 m (40 and 45 ft.) headers. It does NOT include all
parts in the shipment.
All bags contain parts within a section of this list. For identification, the bags are labeled with a letter and title.
Table 12.1 Bagged Parts List for 12.2 and 13.7 m (40 and 45 Ft) Headers
Part #
Description
Quantity
12.2 m
(40 ft.)
13.7 m
(45 ft.)
Bag A – Cutterbar Components
118344
Sickle Guard
33
118162
Clip – Hold-Down
11
18654
Nut – Hex 7/16 NC GR5 ZP
66
118154
Bolt – HH 3/8 NC X 5/8 TFL GR8 ZP
11
118193
Nut – Flange Hex .375 NC
11
120558
Bolt
66
125418
Support – Split C-Bar Connection
10
253552
Support – Split C-Bar Connection
0
1
129297
Wearplate – Cutterbar
44
118345
Knife Guard
11
Draper
220639
Draper – 40 ft. WCCO
10
172197
Draper – 40 ft. LEGG
00
Bag B – Disc Assembly Parts
CAM END (Discs are Secured to Right Cam)
105136
Screw – Machine
26 26
105135
Screw – Machine
66
50186
Nut – Flange Lock SM Face DT 0.500-13UNC GR5
32 32
MID SPAN (Discs are Secured to Right Cam)
105136
Screw – Machine
66
105135
Screw – Machine
18 18
50186
Nut – Flange Lock SM Face DT 0.500-13UNC GR5
24 24
TAIL END (Discs Are Secured to Right Cam)
105136
Screw – Machine
11 11
