Setting Maximum Work Height – New Holland CR Series
NOTE:
This section applies only to 2015 and later CR models (6.80, 6.90, 7.90, 8.90, 9.90, and 10.90). For other pre-2015 New
Holland combine models, refer to 9.1.18 New Holland Combines – CR/CX Series – 2014 and Prior, page 462.
1016056
A
Figure 9.398: New Holland Combine Display
1. Select TOOLBOX (A) on the main screen. The TOOLBOX
screen displays.
1016063
A
B
Figure 9.399: New Holland Combine Display
2. Select FEEDER (A). The FEEDER SETUP screen displays.
3. Select MAXIMUM WORK HEIGHT field (B).
1016064
Figure 9.400: New Holland Combine Display
4. Set MAXIMUM WORK HEIGHT to desired value.
5. Press SET and then press ENTER.
