215184 411 Revision A
Calibrating the Header – Gleaner S9 Series
The auto header control functions are configured on the HEADER SETTINGS page.
WARNING
Clear the area of other persons, pets etc. Keep children away from machinery. Walk around the machine to be sure no
one is under, on, or close to it.
NOTE:
Changes may have been made to the combine controls or display since this document was published. Refer to the combine
operator’s manual for updates.
Figure 9.232: Combine Main Menu
1. On the COMBINE MAIN MENU, touch HEADER
SETTINGS (A).
Figure 9.233: Header Settings Page
2. Touch CALIBRATE (A) at the bottom right of the page. The
HEADER CALIBRATION page displays.
SETTING UP AUTO HEADER HEIGHT CONTROL
